Check Valves

Prevent backflow and ensure system integrity.
Sort By Sort By: Featured
[TTSCV-14-1000-E25-42A2ST00] Model TTSCV Tilting Type Swing Check Valve with Lever & Weight, DN1000-PN25, EPDM

Model TTSCV Tilting Type Swing Check Valve with Lever & Weight, DN1000-PN25, EPDM

Tilting Type Swing Check Valve with Lever and Weight, Flange connection acc.DIN EN 1092-2, Face to face acc. DIN EN 558, series 14 (F4), Body: GGG50 / EN-GJS-500-7, Spindle: AISI-420/EN 1.4021 (X20Cr13), Disc Sealing: EPDM, Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Bolts: stainless steel A2-70/SS304. Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
20,084.00 €
[TTSCV-14-1000-E40-42A2ST00] Model TTSCV Tilting Type Swing Check Valve with Lever & Weight, DN1000-PN40, EPDM

Model TTSCV Tilting Type Swing Check Valve with Lever & Weight, DN1000-PN40, EPDM

Tilting Type Swing Check Valve with Lever and Weight, Flange connection acc.DIN EN 1092-2, Face to face acc. DIN EN 558, series 14 (F4), Body: GGG50 / EN-GJS-500-7, Spindle: AISI-420/EN 1.4021 (X20Cr13), Disc Sealing: EPDM, Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Bolts: stainless steel A2-70/SS304. Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
28,117.00 €
Model FCV Non Return Flap Check Valve, DN100-PN10/16, NBR (copy) Rückflussverhinderer- Flap Check Valve.webp

Model FCV Non Return Flap Check Valve, DN100-PN10/16, NBR (copy)

Non Return Flap Check Valve, Flange connection acc.DIN EN 1092-2, Face to face acc. DIN EN 558, series 48 (F6), Resilient seated, 100% free opening, Body: GGG50 / EN-GJS-500-7, Bolts: stainless steel A2-70/SS304. Including A2 Drain Plug. Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK.
126.29 €
[BCV-48-0020-IT-N16-xxA2ST1] Model BCV Ball Check Valve, DN20-3/4 inch, PN10/16, NBR, draadaansluiting

Model BCV Ball Check Valve, DN20-3/4 inch, PN10/16, NBR, draadaansluiting

Internal Threaded,  Body, cover and flap : GGG50,  Ball: steel/cast iron + NBR rubber, Bolts: stainless steel A2-304, Coating: fushion bonded epoxy powder coated  (min 250μm) RAL-5015.
25.88 €
[BCV-48-0025-IT-N16-xxA2ST1] Model BCV Ball Check Valve, DN25-1" inch, PN10/16, NBR, draadaansluiting

Model BCV Ball Check Valve, DN25-1" inch, PN10/16, NBR, draadaansluiting

Internal Threaded,  Body, cover and flap : GGG50,  Ball: steel/cast iron + NBR rubber, Bolts: stainless steel A2-304, Coating: fushion bonded epoxy powder coated  (min 250μm) RAL-5015.
25.88 €
[BCV-48-0032-IT-N16-xxA2ST1] Model BCV Ball Check Valve, DN32-1 1/4" inch, PN10/16, NBR, draadaansluiting

Model BCV Ball Check Valve, DN32-1 1/4" inch, PN10/16, NBR, draadaansluiting

Internal Threaded,  Body, cover and flap : GGG50,  Ball: steel/cast iron + NBR rubber, Bolts: stainless steel A2-304, Coating: fushion bonded epoxy powder coated  (min 250μm) RAL-5015.
28.50 €
[BCV-48-0040-IT-N16-xxA2ST1] Model BCV Ball Check Valve, DN40-1 1/2" inch, PN10/16, NBR, draadaansluiting

Model BCV Ball Check Valve, DN40-1 1/2" inch, PN10/16, NBR, draadaansluiting

Internal Threaded,  Body, cover and flap : GGG50,  Ball: steel/cast iron + NBR rubber, Bolts: stainless steel A2-304, Coating: fushion bonded epoxy powder coated  (min 250μm) RAL-5015.
33.96 €
[BCV-48-0050-IT-N16-xxA2ST1] Model BCV Ball Check Valve, DN50-2" inch, PN10/16, NBR, draadaansluiting

Model BCV Ball Check Valve, DN50-2" inch, PN10/16, NBR, draadaansluiting

Internal Threaded,  Body, cover and flap : GGG50,  Ball: steel/cast iron + NBR rubber, Bolts: stainless steel A2-304, Coating: fushion bonded epoxy powder coated  (min 250μm) RAL-5015.
39.58 €
[BCV-48-0050-N16-xxA2ST1] Model BCV Ball Check Valve, DN50, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN50, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
65.83 €
[BCV-48-0065-N16-xxA2ST1] Model BCV Ball Check Valve, DN65, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN65, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
81.02 €
[BCV-48-0080-N16-xxA2ST1] Model BCV Ball Check Valve, DN80, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN80, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
95.78 €
[BCV-48-0100-N16-xxA2ST1] Model BCV Ball Check Valve, DN100, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN100, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
120.06 €
[BCV-48-0125-N16-xxA2ST1] Model BCV Ball Check Valve, DN125, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN125, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
187.85 €
[BCV-48-0150-N16-xxA2ST1] Model BCV Ball Check Valve, DN150, PN10/16, NBR, Flanged

Model BCV Ball Check Valve, DN150, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
232.02 €
[BCV-48-0200-N10-xxA2ST1] Model BCV Ball Check Valve, DN200, PN10, NBR, Flanged

Model BCV Ball Check Valve, DN200, PN10, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
423.88 €
[BCV-48-0200-N16-xxA2ST1] Model BCV Ball Check Valve, DN200, PN16, NBR, Flanged

Model BCV Ball Check Valve, DN200, PN16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
423.88 €
[BCV-48-0250-N10-xxA2ST1] Model BCV Ball Check Valve, DN250, PN10, NBR, Flanged

Model BCV Ball Check Valve, DN250, PN10, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
806.26 €
[BCV-48-0300-N10-xxA2ST1] Model BCV Ball Check Valve, DN300, PN10, NBR, Flanged

Model BCV Ball Check Valve, DN300, PN10, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
1,267.16 €
[BCV-48-0350-N10-xxA2ST1] Model BCV Ball Check Valve, DN350, PN10, NBR, Flanged

Model BCV Ball Check Valve, DN350, PN10, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
1,708.69 €
[BCV-48-0400-N10-xxA2ST1] Model BCV Ball Check Valve, DN400, PN10, NBR, Flanged

Model BCV Ball Check Valve, DN400, PN10, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug
2,292.82 €
