Gate Valves

Ideal for on/off control in high-pressure systems.
Sort By Sort By: Featured
[RSGV-14-1000-E10-42A2ST02] Model RSGV F4 Gate Valve, DN1000-PN10, EPDM with Gearbox & Handwheel

Model RSGV F4 Gate Valve, DN1000-PN10, EPDM with Gearbox & Handwheel

DVGW-W270/WRAS Approved Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with EPDM (DVGW W-270), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
18,000.00 €
[RSGV-14-1000-E16-42A2ST02] Model RSGV F4 Gate Valve, DN1000-PN16, EPDM with Gearbox & Handwheel

Model RSGV F4 Gate Valve, DN1000-PN16, EPDM with Gearbox & Handwheel

DVGW-W270/WRAS Approved Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with EPDM (DVGW W-270), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
18,000.00 €
[RSGV-14-0700-N10-A4A2ST02] Model RSGV F4 Gate Valve, SS-316, DN700-PN10, NBR with Gearbox & Handwheel

Model RSGV F4 Gate Valve, SS-316, DN700-PN10, NBR with Gearbox & Handwheel

Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with NBR, Spindle: A4-SS316 (1.4401), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK.
9,569.00 €
[RSGV-14-0800-N10-A4A2ST02] Model RSGV F4 Gate Valve, SS-316, DN800-PN10, NBR with Gearbox & Handwheel

Model RSGV F4 Gate Valve, SS-316, DN800-PN10, NBR with Gearbox & Handwheel

Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with NBR, Spindle: A4-SS316 (1.4401), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK.
11,212.00 €
[RSGV-14-0900-N10-A4A2ST02] Model RSGV F4 Gate Valve, SS-316, DN900-PN10, NBR with Gearbox & Handwheel

Model RSGV F4 Gate Valve, SS-316, DN900-PN10, NBR with Gearbox & Handwheel

Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with NBR, Spindle: A4-SS316 (1.4401), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK.
14,199.00 €
[RSGV-14-1000-N10-A4A2ST02] Model RSGV F4 Gate Valve, SS-316, DN1000-PN10, NBR with Gearbox & Handwheel

Model RSGV F4 Gate Valve, SS-316, DN1000-PN10, NBR with Gearbox & Handwheel

Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge fully covered with NBR, Spindle: A4-SS316 (1.4401), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK.
18,000.00 €
[MSGV-15-0050-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN50-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN50-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
543.00 €
[MSGV-15-0065-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN65-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN65-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
829.00 €
[MSGV-15-0080-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN80-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN80-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
975.00 €
[MSGV-15-0100-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN100-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN100-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
1,102.00 €
[MSGV-15-0150-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN150-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN150-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
2,803.00 €
[MSGV-15-0200-S40-42A2ST09] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN200-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN200-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
3,540.00 €
[MSGV-15-0250-S40-42A2ST02] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN250-PN40 with Gearbox & Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN250-PN40 with Gearbox & Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
5,696.00 €
[MSGV-15-0300-S40-42A2ST02] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN300-PN40 with Gearbox & Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN300-PN40 with Gearbox & Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
6,250.00 €
[MSGV-14-0050-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN50-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN50-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
153.00 €
[MSGV-14-0065-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN65-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN65-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
179.00 €
[MSGV-14-0080-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN80-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN80-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
217.00 €
[MSGV-14-0100-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN100-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN100-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
230.00 €
[MSGV-14-0125-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN125-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN125-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
401.00 €
[MSGV-14-0150-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN150-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN150-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
431.00 €
