Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN50-PN40 with Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN50-PN40 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015  min 250  µm  acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
543.00 € 543.00 € (Tax excluded)

  • DN Size
  • Connection / Pressure (PN)
  • Face to Face
  • Sealing Type
  • Design
  • Body Material
  • Spindle
  • Coating
  • Actuation
  • Flow Direction
  • Warranty Period
6 Units left in stock
Add to cart
Add to wishlist
DN Size DN50
Connection / Pressure (PN) Flanged PN40 (EN1092)
Face to Face EN-558-1 Series 15 (F5)
Sealing Type SS-304 Metal Sealing
Design Double Flanged
Body Material GGG50 (EN-GJS-500-7)
Spindle AISI-420 (A2-DIN 1.4021)
Coating RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Actuation Handwheel
Flow Direction Bi-Directional
Warranty Period 5 YEARS Warranty
DN Size: DN50
Connection / Pressure (PN): Flanged PN40 (EN1092)
Face to Face: EN-558-1 Series 15 (F5)
Sealing Type: SS-304 Metal Sealing
Design: Double Flanged
Body Material: GGG50 (EN-GJS-500-7)
Spindle: AISI-420 (A2-DIN 1.4021)
Coating: RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Actuation: Handwheel
Flow Direction: Bi-Directional
Warranty Period: 5 YEARS Warranty
