Gate Valves

Ideal for on/off control in high-pressure systems.
Sort By Sort By: Featured
[MSGV-15-0250-S40-42A2ST02] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN250-PN40 with Gearbox & Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN250-PN40 with Gearbox & Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
5,696.00 €
[MSGV-15-0300-S40-42A2ST02] Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN300-PN40 with Gearbox & Handwheel

Model MSGV F5 - SS-304 Metal Seated Gate Valve, DN300-PN40 with Gearbox & Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 15 , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG40 / EN-GJS-400-15, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
6,250.00 €
[MSGV-14-0050-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN50-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN50-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
153.00 €
[MSGV-14-0065-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN65-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN65-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
179.00 €
[MSGV-14-0080-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN80-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN80-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
217.00 €
[MSGV-14-0100-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN100-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN100-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
230.00 €
[MSGV-14-0125-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN125-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN125-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
401.00 €
[MSGV-14-0150-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN150-PN10/16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN150-PN10/16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
431.00 €
[MSGV-14-0200-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN200-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN200-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
628.00 €
[MSGV-14-0250-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN250-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN250-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
1,190.00 €
[MSGV-14-0300-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN300-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN300-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
1,329.00 €
[MSGV-14-0350-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN350-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN350-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
2,002.00 €
[MSGV-14-0400-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN400-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN400-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
2,752.00 €
[MSGV-14-0450-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN450-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN450-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
4,417.00 €
[MSGV-14-0500-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN500-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN500-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
4,697.00 €
[MSGV-14-0600-S10-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN600-PN10 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN600-PN10 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
6,806.00 €
[MSGV-14-0200-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN200-PN16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN200-PN16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
628.00 €
[MSGV-14-0250-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN250-PN16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN250-PN16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
1,190.00 €
[MSGV-14-0300-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN300-PN16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN300-PN16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
1,329.00 €
[MSGV-14-0350-S16-42A2ST09] Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN350-PN16 with Handwheel

Model MSGV F4 - SS-304 Metal Seated Gate Valve, DN350-PN16 with Handwheel

Metal Seated Flanged Gate Valve acc. to DIN EN 1171/DIN EN 1074-1&2 , DIN EN 558-1 Series 14 (F4) , Flanges acc. DIN EN 1092, Body, Wedge & Bonnet: GGG50 / EN-GJS-500-7, Wedge & Body Sealing: Stainless Steel A2-AISI-304 (EN-1.4301), Spindle: AISI-420/EN 1.4021 (X20Cr13), Bolts: Stainless Steel A2-AISI-304 (EN-1.4301), Stem nut: Brass, Coating: Epoxy Coating RAL-5015 min 250 µm acc. RAL-GSK. All materials in direct contact with Drinking Water acc. UBA-KTW and DVGW W-270.
2,002.00 €
