Model L-BFV Concentric LUG Butterfly Valve, DN600-PN10, EPDM. Operation: Gearbox & Handwheel

Model L-BFV Concentric LUG Butterfly Valve, DN600-PN10, EPDM. Operation: Gearbox & Handwheel

LUG Type Concentric Butterfly Valve acc. DIN-EN-593, flanged acc. EN1092-2, face to face length acc. to EN 558-1 series 20, Body: GGG-50 / EN-GJS-500-7, Sealing: EPDM, Disc: CF8M (SS-316 / 1.4408), Spindel: AISI-420 / EN 1.4021 (X20Cr13). Coating: Epoxy Coating RAL-5015  min 250 µm  acc. RAL-GSK. All materials in direct contact with drinking water comply with UBA-KTW, KTW-BWGL, and DVGW W-270.
3,405.00 € 3,405.00 € (Tax excluded)

Forecasted: 0
Please contact us for updated Stock Availability
  • DN Size
  • Connection / Pressure (PN)
  • Face to Face
  • Sealing Type
  • Design
  • Body Material
  • Spindle
  • Coating
  • Actuation
  • Flow Direction
  • Warranty Period
6 Units left in stock
Add to cart
Add to wishlist
DN Size DN600
Connection / Pressure (PN) Flanged PN10 (EN1092)
Face to Face EN-558-1 Series 20 (K1)
Sealing Type EPDM (DVGW W270)
Design Lug Type
Body Material GGG50 (EN-GJS-500-7)
Spindle AISI-420 (A2-DIN 1.4021)
Coating RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Actuation Gearbox & Handwheel
Flow Direction Bi-Directional
Warranty Period 5 YEARS Warranty
Contact Us
DN Size: DN600
Connection / Pressure (PN): Flanged PN10 (EN1092)
Face to Face: EN-558-1 Series 20 (K1)
Sealing Type: EPDM (DVGW W270)
Design: Lug Type
Body Material: GGG50 (EN-GJS-500-7)
Spindle: AISI-420 (A2-DIN 1.4021)
Coating: RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Actuation: Gearbox & Handwheel
Flow Direction: Bi-Directional
Warranty Period: 5 YEARS Warranty

Downloads

Model L-BFV DN40-DN1200 PN10/16/25
L-BFV_DN40-600_PN10-16-25_2026-03-16.pdf
