Model BCV Ball Check Valve, DN65, PN10/16, NBR, Flanged

Double flanged type, Face to Face acc. to EN 558-1 series 48 (F6), Body, cover and flap : GGG50, Ball with NBR rubber, Bolts, nuts and washers: stainless steel A2-304, Coating: fushion bonded epoxy powder coated (min 250μm) RAL-5015. Including A2 Drain Plug

81.02 € (Tax excluded)

DN Size
- DN65
Connection / Pressure (PN)
- Flanged PN10/16 (EN1092)
Design
- Double Flanged
Face to Face
- EN-558-1 Series 48 (F6)
Sealing Type
- NBR
Body Material
- GGG50 (EN-GJS-500-7)
Coating
- RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Flow Direction
- Uni-Directional
Warranty Period
- 5 YEARS Warranty

6 Units left in stock

Add to cart

Add to wishlist

Specifications

DN Size	DN65
Connection / Pressure (PN)	Flanged PN10/16 (EN1092)
Design	Double Flanged
Face to Face	EN-558-1 Series 48 (F6)
Sealing Type	NBR
Body Material	GGG50 (EN-GJS-500-7)
Coating	RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)
Flow Direction	Uni-Directional
Warranty Period	5 YEARS Warranty

DN Size: DN65

Connection / Pressure (PN): Flanged PN10/16 (EN1092)

Design: Double Flanged

Face to Face: EN-558-1 Series 48 (F6)

Sealing Type: NBR

Body Material: GGG50 (EN-GJS-500-7)

Coating: RAL-5015 with WRAS-DVGW-W270 Approval (min 250 microns)

Flow Direction: Uni-Directional

Warranty Period: 5 YEARS Warranty
