Accessoires

Column stand, floor column, stainless steel construction V2A (1.4301/1.4305), standard operating height to operating axis H=900mm, column stand with internal spindle extension and shaft end with keyway, spindle guide made of RG7. Self-supporting frame construction with stiffeners against transverse and rotational forces, pre-assembled and ready for operation. Rectangular base plate for anchoring to a concrete structure.

Column stand, floor column, stainless steel construction V2A (1.4301/1.4305), standard operating height to operating axis H=900mm, column stand with internal spindle extension and shaft end with keyway, spindle guide made of RG7. Self-supporting frame construction with stiffeners against transverse and rotational forces, pre-assembled and ready for operation. Rectangular base plate for anchoring to a concrete structure.

Column stand, floor column, stainless steel construction V2A (1.4301/1.4305), standard operating height to operating axis H=900mm, column stand with internal spindle extension and shaft end with keyway, spindle guide made of RG7. Self-supporting frame construction with stiffeners against transverse and rotational forces, pre-assembled and ready for operation. Rectangular base plate for anchoring to a concrete structure.

Telescopic Underground Spindel Extension kit T3 stainless steel (DIN 3223 C and E), rod stainless steel (1.4301), coupling sleeve (for spindle or shaft) and square protector (according to DIN 3223 C or E) made of AISI 304 stainless steel with stainless steel clip pin. Self-locking in every extension position thanks to a PE sealing sleeve on the square tube. Torques up to 500 Nm. Completely dirt and water repellent.

Rod made of hot-dip galvanized steel according to DIN EN 10240 (alternatively stainless steel), coupling sleeve made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304). Square protector made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304), suitable for operating wrench DIN 3223 C. Tool-free assembly of the installation kit with the stainless steel clip pin. Connecting pins made of stainless steel 1.4301. Pull-out protection of the rod min. 150 N. Self-locking in every extension position due to PE sealing sleeve on the square tube. Torque specifications according to GW336. Three-part PE protective pipe system with additional ribbed protective pipe, welded centering cap and welded round bell according to GW336. Completely dirt and water repellent. Includes a marking disc usable on both sides (gas and water) and a universal bell sealing insert.

Rod made of hot-dip galvanized steel according to DIN EN 10240 (alternatively stainless steel), coupling sleeve made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304). Square protector made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304), suitable for operating wrench DIN 3223 C. Tool-free assembly of the installation kit with the stainless steel clip pin. Connecting pins made of stainless steel 1.4301. Pull-out protection of the rod min. 150 N. Self-locking in every extension position due to PE sealing sleeve on the square tube. Torque specifications according to GW336. Three-part PE protective pipe system with additional ribbed protective pipe, welded centering cap and welded round bell according to GW336. Completely dirt and water repellent. Includes a marking disc usable on both sides (gas and water) and a universal bell sealing insert.

Rod made of hot-dip galvanized steel according to DIN EN 10240 (alternatively stainless steel), coupling sleeve made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304). Square protector made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304), suitable for operating wrench DIN 3223 C. Tool-free assembly of the installation kit with the stainless steel clip pin. Connecting pins made of stainless steel 1.4301. Pull-out protection of the rod min. 150 N. Self-locking in every extension position due to PE sealing sleeve on the square tube. Torque specifications according to GW336. Three-part PE protective pipe system with additional ribbed protective pipe, welded centering cap and welded round bell according to GW336. Completely dirt and water repellent. Includes a marking disc usable on both sides (gas and water) and a universal bell sealing insert.

Rod made of hot-dip galvanized steel according to DIN EN 10240 (alternatively stainless steel), coupling sleeve made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304). Square protector made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304), suitable for operating wrench DIN 3223 C. Tool-free assembly of the installation kit with the stainless steel clip pin. Connecting pins made of stainless steel 1.4301. Pull-out protection of the rod min. 150 N. Self-locking in every extension position due to PE sealing sleeve on the square tube. Torque specifications according to GW336. Three-part PE protective pipe system with additional ribbed protective pipe, welded centering cap and welded round bell according to GW336. Completely dirt and water repellent. Includes a marking disc usable on both sides (gas and water) and a universal bell sealing insert.

Column stand, floor column, stainless steel construction V4A (1.4404/1.4571), standard operating height to operating axis H=900mm, column stand with internal spindle extension and shaft end with keyway, spindle guide made of RG7. Self-supporting frame construction with stiffeners against transverse and rotational forces, pre-assembled and ready for operation. Rectangular base plate for anchoring to a concrete structure.

Max. 500 Nm, without Valve Coupling/Squarehead

Max. 500 Nm, without Valve Coupling/Squarehead

Max. 500 Nm, without Valve Coupling/Squarehead

Straßenkappe DIN 4056, für Absperrschieber WASSER, verstellbar. Unterteil aus glasfaserverstärktem, hitzebeständigem Kunststoff, Oberteil komplett aus Gusseisen GJL-200 (GG20). Deckelsitz konisch. Im Deckel integrierter Kunststoff-Zentrierring zur Vermeidung von Verschleiß und Klappergeräuschen. Stufenlos höhenverstellbar. Oberteil neigbar bis 7°. Abdeckring mit O-Ring zur gleitenden Höhenjustierung und Sicherung gegen Eintritt von Schmutz und Wasser. Deckel aus Gusseisen GJL-200 (GG20) – hochwertiger Korrosionsschutz durch Polyester-Pulverbeschichtung. Sicherheitsbolzen aus Edelstahl (V2A). Temperaturbeständig bis 240°C. Druckbelastung bis 250 KN.

Rod made of hot-dip galvanized steel according to DIN EN 10240 (alternatively stainless steel), coupling sleeve made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304). Square protector made of GJS400-15, galvanized steel according to DIN EN 12329 and DIN 50961 (alternatively stainless steel AISI 304), suitable for operating wrench DIN 3223 C. Tool-free assembly of the installation kit with the stainless steel clip pin. Connecting pins made of stainless steel 1.4301. Pull-out protection of the rod min. 150 N. Self-locking in every extension position due to PE sealing sleeve on the square tube. Torque specifications according to GW336. Three-part PE protective pipe system with additional ribbed protective pipe, welded centering cap and welded round bell according to GW336. Completely dirt and water repellent. Includes a marking disc usable on both sides (gas and water) and a universal bell sealing insert.
